Elevate your trolling motor’s performance with the Norsk Lithium® 24V 90AH Heated LiFePO4 Lithium Trolling Motor Battery, built specifically for 24V trolling motors. Engineered for marine enthusiasts, this battery combines cutting-edge technology with rugged durability to deliver unmatched power on the water. Designed to excel even in harsh conditions, it features Thermal Core Heating Technology™ that activates during charging, ensuring optimal charging in cold weather.
Warranty:10 Years +2 with registration through Norsk Guardian™
24V 90AH HEATED LIFEPO4 LITHIUM TROLLING MOTOR BATTERY – NORSK LITHIUM
Elevate your trolling motor’s performance with the Norsk Lithium 24V 90AH Heated LiFePO4 Lithium Trolling Motor Battery. Engineered for marine enthusiasts, this battery combines cutting-edge technology with rugged durability to deliver unmatched power on the water.
Designed to excel even in harsh conditions, this battery features Thermal Core Heating Technology™ that activates during charging, ensuring optimal charge performance in cold weather. This innovative heating solution protects the battery from the detrimental effects of low temperatures, preserving its capacity and extending its lifespan.
Beyond its heating capabilities, this battery also boasts advanced Deep Sleep™ functionality. This feature can be accessed through the Norsk Guardian® App and it significantly reduces self-discharge and prolongs its overall lifespan. As a result, you can count on this battery to be ready for action whenever you hit the water.
Crafted from high-quality materials, the Norsk Lithium® Trolling Motor Battery is built to withstand the rigors of marine environments. Whether you’re exploring tranquil lakes or navigating choppy seas, this battery provides reliable, consistent power for your trolling motor.
Upgrade your trolling experience with the Norsk Lithium® 24V 90AH Heated LiFePO4 Lithium Trolling Motor Battery and enjoy unparalleled performance and reliability on every adventure.
DEEP SLEEP™
Disconnect power to your battery’s terminals using this feature in the Norsk Guardian® app to eliminate fully-discharged batteries caused by phantom draw – storing your battery has never been easier!
THERMAL CORE HEATING TECHNOLOGY
Our proprietary Thermal Core Heating Technology™ checks the temperature of the cells inside the battery and reroutes the inbound current from the charger to warm the cells if the cell temperature is below 32F. / 0C. Once the internal cell temperature has been increased to a safe charging temperature, the current from the charger is routed to the cells so a safe charge can take place. With the addition of full potting with thermally conductive epoxy, custom heat pads, and our proprietary heating control algorithm, NOBODY does heated batteries better!
BCI-COMPLIANT CASES
Norsk Lithium 24V Deep Cycle batteries are constructed in BCI-compliant cases, ensuring they fit in the same space as a Group 31 lead-acid or AGM battery. This eliminates the need for an oversized proprietary battery tray.
ONE-TOUCH POWER MANAGEMENT
The Power Management button, found on all Norsk Lithium® marine batteries, allows the user to quickly check State of Charge, and manage advanced features such as ESR and Deep Sleep™ or reset the BMS.
IP67 WATERPROOF
IP67 Waterproof ensures that your Norsk Lithium® Marine Battery is fully protected against dust and capable of withstanding immersion in water up to 1 meter deep for 30 minutes. This high level of protection guarantees that your battery remains operational in the harshest marine environments, providing reliable performance and durability.
NORSK GUARDIAN APP INTEGRATION
Seamlessly manage your battery’s performance with the Norsk Guardian® App. Monitor battery status, control the Deep Sleep™ mode, and access Emergency Start Reserve [ESR] with ease, all from the convenience of your smartphone.
ADVANCED FEATURES
24V TROLLING POWER
The Norsk Lithium 24V battery line delivers reliable, long-lasting power for all leading trolling motor brands.
MAXIMUM THRUST & POWER
Unleash full torque and relentless power-engineered to drive both classic trolling motors and next-generation brushless designs.
EASY BATTERY STORAGE
Deep Sleep™ allows the user to disconnect the power from the battery terminals with the power management button or from the Norsk Guardian® App.
FREE MOBILE APP
Connect to the FREE Norsk Guardian® App & monitor critical battery info & access advanced features such as Deep Sleep™.
POWER MANAGEMENT
Allows the user to quickly check the state of charge & access advanced features such as Deep Sleep™.
INTERNAL ADVANCED BMS
Provides a variety of safety protections like Short Circuit, Overcharging, and Reverse Polarity.
BCI COMPLIANT
All Norsk Lithium Batteries adhere to BCI specifications, Group 27 & 31, eliminating the need for proprietary battery trays simplifying installations.
IP67 WATERPROOF
Sealed and ready for action, our IP67-rated batteries are built to handle the toughest conditions.
FREE APP DOWNLOAD
NORSK GUARDIAN
The Norsk Lithium Guardian App connects to your Norsk Lithium batteries via Bluetooth, enabling simultaneous monitoring of multiple batteries. Track battery health, charging status, and receive real-time alerts—right on your phone.
CORE SPECIFICATIONS
| Battery Type |
Lithium Iron Phosphate (LiFePO4) |
| Product Model |
B24090GH |
| Product Name |
24V 90Ah LiFePO4 Guardian Heated Battery |
| Cell Configuration |
8S6P |
| Nominal Capacity |
90Ah |
| Nominal Voltage |
25.6V |
| Weight |
Approx. 15.5 kg / 34.2 lb |
| Dimensions |
Group 31 – Approx. 12.99 x 6.81 x 8.11 in. / 329 x 173 x 206 mm |
CHARGING & DISCHARGING
| Standard Charging Voltage |
28.4V |
| Maximum Charge Voltage |
28.4V |
| Standard Charge Current |
45A |
| Maximum Continuous Discharge Current |
90A at 10°C to 60°C |
| Discharge Cutoff Voltage |
17.6V from -20°C to 0°C
20.0V from 0°C to 60°C |
| Operating Voltage Range |
17.6V-28.8V from -20°C to 0°C
20.0V-28.8V from 0°C to 60°C |
TEMPERATURE RATINGS
| Charging Temperature Range |
-20°C to 45°C |
| Discharging Temperature Range |
-20°C to 60°C |
| Storage Temperature |
Up to 7 days: -20°C to 60°C
Up to 3 months: -20°C to 40°C
Up to 1 year: -20°C to 25°C |
| Storage Humidity |
≤ 85% |
SMART FEATURES & PROTECTION
| Battery Indicator |
LED state-of-charge display: 25%, 50%, 75%, 100% |
| Power Management Button |
Quick press: Check state of charge / disable Deep Sleep
Long press, 3 lights: Enable Deep Sleep
Long press, 4 lights: Reset BMS |
| BMS Protection |
- Overcharge
- Over-Discharge
- Overcurrent
- Short Circuit
- High Temp Shutoff
- Low Temp Shutoff
- Deep Sleep™
- Bluetooth Communication
- Thermal Core Heating Technology™
|
CYCLE LIFE & CERTIFICATIONS
| Cycle Life |
4,000+ cycles at ≥70% state of health |
| Certifications |
FCC, UN38.3, ISED |
THE NORSK ADVANTAGE
Our batteries stem from the dedication of outdoor enthusiasts relentlessly pursuing advanced rechargeable lithium technology to power their passions. Recognizing the urgency of a robust power source, the Norsk 24V 90AH HEATED LiFePO4 Lithium Trolling Motor Battery is designed to endure over 4,000 charge cycles, backed by an exceptional warranty. Enjoy a standard 10-year warranty, plus an additional 2 years when you sign up for the Norsk Guardian® App, ensuring enduring performance. Whether you’re braving the cold on a fishing trip or embarking on an off-grid adventure, you can trust Norsk Lithium® to deliver reliable power when you need it most.
